For many years anodizers used almost any convent cathode material, from the actual tank wall to the lead coils used for cooling in sulfuric acid anodizing baths. Little attention was paid to the type of material or the anode to cathode ratio. As operations became more sophisticated and research on this subject was accomplished, and specific recommendations on the ratio and material became available.The consensus opinion was the best material for the cathodes was aluminum and specifically 6063t6 alloy. In addition the ratio of 3 sq feet of anode to 1 sq foot of aluminum cathode gave the most consistent anodizing. Attempting to accomplish this ratio in a job shop environment is difficult but the closer you are to this ratio the better your overall anodizing performance will be. Anodize USA went one step further and designed the "snappable aluminum cathode system" to insure years of reliable, flexible and easily serviceable cathode design. It offers the following advantages over other systems:

1) Lower voltage required to do the same work.
2) Long life (some cathodes in service over 3 years)
3) No undesirable metals to contaminate the anodizing bath
4) High surface area per cathode
5) Easily replaced
6) Uses less tank space
7) Less heat build up
8) Overall lower operating cost
9) Simpler to change the cathode area

Anodize USA will design and fabricate a complete aluminum cathode bussing system for your new or existing anodizing tank. It is designed based on tank size, work load and rectifier capacity. Your aluminum cathode system comes ready to assemble with appropriate hardware making for an easy field installation. These systems are custom designed to your operating parameters and can be fabricated and shipped in 2-3 weeks. Anode bar setups are also available. Call for pricing.

For more information click here
